Home23L Ethylene Oxide Sterilizer

23L Ethylene Oxide Sterilizer
Model : ST-EO40

Effective Volume (L) : 23
Working Temperature (℃) : 50±3
Heating Method : Electric heating
Sterilization Time : 0-99 hours adjustable
Selected Gas : Pure ethylene oxide gas

You can later choose whether you want a quote, or if you place a firm order.

Product Description

Ethylene Oxide Sterilizer Specifications:

Model ST-EO40
Effective Volume 23L
Product Form Desktop
Heating Method Electric heating
Working Temperature 50℃ ±3℃
Selected Gas Pure ethylene oxide gas
Sterilization Time 0-99 hours adjustable
Temperature Display 3.5 inch LCD display
Maximum Anti-stress Value -140kpa
Voltage/Frequency(V/Hz) AC220V, 50Hz
Power 3.3KW
Size(WxDxH) Internal (mm) Diameter x Depth : Ø246×450
External (mm) 730x510x410
Shipping Size (WxDxH)  (mm) 900x700x600
N.W./G.W. (kg) 56/76



Ethylene Oxide Sterilizer Features:

Ethylene oxide sterilizer is mainly through its non-specific alkylation with genetic materials such as protein and DNA / RNA in microorganisms, resulting in the denaturation of proteins and genetic materials, and finally the death of microorganisms due to blocked metabolism.

  1. Humidification: Utilizes steam degradation analysis method with built-in steam generator for comprehensive and uniform humidification and heating while minimizing water mist.
  2. 3.5″ LCD screen: Equipped with a filter for stability, prolonging the service life and accuracy of the control screen.
  3. Power-off memory function: Preserves sterilization data and automatically resumes unfinished work procedures in case of accidents or power loss.
  4. Safety protection function: Includes alarm protection for abnormal temperature, ultra-high temperature, abnormal pressure, low vacuum rate, residual faults, phase sequence errors, and power shortage in the sterilization chamber to prevent further issues.
  5. Ethylene Oxide Consumable: Steam EO sterilization pouch roll, chemistry indicator strip, biological indicator, chemistry indicator tape, chemical indicator label, EO sterilization gas, medical non-woven fabric, sealing machine, EO sterilization gas.
