Climate Chamber Specifications:
| Model |
ICB-250C |
ICB-350C |
| Capacity(L) |
250 |
350 |
| Circulation Mode |
Forced convection |
| Size(WxDxH) |
Internal (mm) |
560×420×1050 |
560×530×1200 |
| External (mm) |
660×660×1700 |
670×730×1880 |
| Temperature |
Range (℃) |
With lighting: 10~60; Without lighting: 4~60 |
| Fluctuation (℃) |
±1 |
| Resolution (℃) |
0.1 |
| Uniformity (℃) |
±1 |
±2 |
| Sensor |
PT100 |
| Humidity |
Range |
50~90%RH |
| Stability |
±5 ~ ±7 % |
| Method |
Internal |
| Sensor |
High precision anti-condensation |
| Illumination(Lx) |
0~12000 |
0~15000 |
| Illumination Control |
6-level relative illuminance control |
| Controller |
PID |
| Display |
Large high efinition LCD |
| Timer |
1~9999min (Optional 30xsegmentsx100cycles) |
| Material |
Internal |
Stainless steel |
| External |
Cold rolled steel electrostatic spraying exterior |
| Shelves |
3 |
| Internal Socket |
Optional |
| Refrigerant |
R134a (CFC free) |
| Defrosting Mode |
Automatic |
| Safety Device |
Visible & Audible over temperaure, over humidity, water shortage alarm; leakage protector |
| Electricity |
Voltage/Frequency |
AC 220/110V, 50/60Hz |
| Consumption (W) |
880 |
1640 |
| N.W./G.W. (kg) |
120/150 |
140/285 |
| Shipping Size (WxDxH) (mm) |
820x800x1920 |
1020x920x2090 |
| Optional |
Test hole(Φ25/50/80/100mm), spare shelf, internal socket, digital independent temp. Limiter, intelligent, LCD procedure temperature controller (Optional USB, RS485/232 port and built-in printer) |
Climate Chamber Features:
Large-screen LCD display for easy monitoring.
Three-stage electric heating defrosting program control for efficient defrosting.
Back suction and bottom vertical air supply circulation system for optimal airflow.
Laser hollowed-out shelves with round holes for improved ventilation and temperature uniformity.
Adjustable shelves with minimum spacing of 30mm for flexible storage.
Reality:
Equipped with leakage protection device for operator and equipment safety.
Temperature control sound and light alarm system for precise monitoring.
Self-diagnosis function to display fault information for easy troubleshooting.
Waterproof stainless steel heating tube for corrosion resistance and long service life.
