HomeConstant Temperature Incubator N/F Series

Model : ICB-50N; ICB-110N; ICB-160N; ICB-50F; ICB-110F; ICB-160F
Capacity(L) : 50; 105; 155; 50; 105; 155
Circulation Mode : Natural convection; Forced convection
Temperature Range : RT+5~70°C
Fluctuation : ≤±0.3°C
Our economical constant temperature incubator is space-saving and ideal for labs with limited space.
You can later choose whether you want a quote, or if you place a firm order.

Product Description

Constant Temperature Incubator Feature:

  1. Programmable P.I.D temperature controller. 4.3″ color touch LCD screen, standard USB data port, easy to record and store experimental data.
  2. With scheduled start function, parameter memory function, safety monitoring function, ambient temperature detection function, etc.
  3. If the temperature inside the incubator is abnormal, it will automatically cut off the power and sound an alarm. Equipped with an external independent temperature protector.
  4. Opening the glass inner door will automatically cut off the power supply of the heater and the inner circulation fan (HDPF-T type) to avoid unnecessary energy consumption.
  5. SUS304 stainless steel shell and chamber. The shelf height is adjustable, and the four corners are semicircular, which is easy to clean.
  6. Automatic door control system: reduce gas exchange and cross contamination between internal and external environments, protect samples and users.
  7. Optional ultraviolet sterilization lamp to directly sterilize the inside of the incubator.

Constant Temperature Incubator Specifications:

Model ICB-50N ICB-110N ICB-160N ICB-50F ICB-110F ICB-160F
Capacity(L) 50 105 155 50 105 155
Circulation Mode Natural convection Forced convection
Internal Size(WxDxH)(mm) 370x350x420 486x409x536 551x474x601 370x350x420 486x409x536 551x474x601
External Size(WxDxH)(mm) 520x633x847 635x673x962 740x742x1027 520x633x847 635x673x962 740x742x1027
Temperature Range RT+5~70°C
Uniformity ±0.5°C at 37°C; ±0.9°C at 50°C ±0.6°C at 37°C; ±1°C at 50°C
Fluctuation ≤±0.3°C
Controller PID Controller; Max. 10 groups × 9 segments program operation
Display 4.3″ color touch LCD screen
Timer 0~9999min
Material Internal SUS304 matte stainless steel
External SUS304 stainless steel
Shelves 2
Exhaust Hole Standard Φ38mm test hole
Power supply AC 220V, 50Hz
Consumption(w) 200 300 400 200 300 400
G.W. (kg) 65 86 109 62 87 111
Shipping Size(WxDxH)(mm) 720×620×1010 770×730×1110 830×830×1190 720×620×1010 770×730×1110 830×830×1160
