Model : LNC-20-50T; LNC-30-50T; LNC-35-50T; LNC-35-80T; LNC-35-125T; LNC-50-50T; LNC-50-125T

LN₂ Capacity (L) : 20 / 31.5 / 35.5 / 35.5 / 35.5 / 50 / 50
Neck Opening (mm) : 50 / 50 / 50 / 80 / 125 / 50 / 125
Static Holding Time (day) : 101 / 159 / 179 / 119 / 86 / 213 / 110
Canister Diameter (mm) : 38 / 38 / 38 / 63 / 97 / 38 / 97

The Special Transport Liquid Nitrogen Tank ensures the safety and stability of liquid nitrogen during transport.

You can later choose whether you want a quote, or if you place a firm order.

Product Description

Liquid Nitrogen Tank Specifications:

Model		LNC-20-50T	LNC-30-50T	LNC-35-50T	LNC-35-80T	LNC-35-125T	LNC-50-50T	LNC-50-125T
Performance
LN₂ Capacity (L)		20	31.5	35.5	35.5	35.5	50	50
Weight Empty (kg)		9.5	12.9	14.2	14.5	14.6	17.2	17.3
Neck Opening (mm)		50	50	50	80	125	50	125
Outer Diameter (mm)		394	462	462	462	462	462	462
Overall Height (mm)		672	705	749	753	748	810	818
Static Evaporation Rate (L/day)		0.2	0.2	0.2	0.3	0.41	0.24	0.45
Static Holding Time (day)		101	159	179	119	86	213	110
Maximum Storage Capacity
Canister Diameter (mm)		38	38	38	63	97	38	97
Canister Height (mm)		120/276	120/276	120/276	120/276	120/276	120/276	120/276
Number of Canisters (ea)		6	6	6	6	6	6	6
Straws Capacity (120 mm Canister)	0.5 ml (ea)	792	792	792	2244	5124	792	5124
Straws Capacity (120 mm Canister)	0.25 ml (ea)	1788	1788	1788	5022	11640	1788	11640
Straws Capacity (276 mm Canister)	0.5 ml (ea)	1284	1284	1284	3624	9048	1284	9048
Straws Capacity (276 mm Canister)	0.25 ml (ea)	2832	2832	2832	8460	20760	2832	20760
Gross Weight (kg)		12.7	15.8	18.1	18.7	19.9	21.88	23.42
Shipping Size(WxDxH) (mm)		425x425x735	480x480x900	480x480x915	480x480x915	480x480x915	480x480x985	480x480x985
Optional Accessories
Lockable Lid		Standard	Standard	Standard	Standard	Standard	Standard	Standard
PU Bag(Protective Jacket)		Standard	Standard	Standard	Standard	Standard	Standard	Standard
SmartCap		/	/	/	/	/	Standard	Standard
Roller Base		/	Standard	Standard	Standard	Standard	Standard	Standard

Special transport liquid nitrogen tanks are economical small liquid nitrogen tanks made of high strength and lightweight aluminum alloy, containing multi-layer insulation to make the product safe, lightweight, specifically designed for biological samples static storage and for transporting biological samples.
