Model : FZ-40V270E; FZ-40V280E; FZ-40V330E; FZ-40V360,; RFZ-40V370; FZ-40V530; FZ-40V1000
Capacity (L) : 268 / 278 / 328 / 358 / 368 / 528 / 936
Shelves / Drawers (Qty) : 3 Shelves / 7 Drawers / 4 Shelves / 4 Shelves & 12 Drawers
2 Shelves & 6 Drawers / 4 Shelves & 18 Drawers / 3 Shelves
Temperature Range (℃) at RT.10~32℃ : -20~-40, adjustable / F:-20～-40, R:2～8
An economical and environmentally friendly solution for safe and reliable general purpose storage. Economic -40℃ freezer is designed to meet the general storage needs of clinical, research and industrial labs.
40°C Upright Freezer Specifications:
| Model |
FZ-40V270E |
FZ-40V280E |
FZ-40V330E |
FZ-40V360 |
RFZ-40V370 |
FZ-40V530 |
FZ-40V1000 |
| Capacity (L) |
268 |
278 |
328 |
358 |
368 |
528 |
936 |
| Size (WxDxH)(mm) |
Internal |
508x455x1137 |
480x415x1460 |
508x455x1393 |
(466x636x625)x2 |
F:580x626x625
R:466x636x625 |
(651×631.5×635)x2 |
1000x700x1335 |
| External |
673x676x1630 |
659x600x1694 |
673x676x1886 |
720x830x1870 |
720x830x1870 |
900x818x1875 |
1304x1000x2017 |
| Temperature Range (℃) at RT. 10~32℃ |
-20~-40 |
-20~-40 |
-20~-40 |
-20~-40 |
F: -20～-40
R: 2～8 |
-20~-40 |
-25~-40 |
| Sensor |
NTC |
NTC |
NTC |
NTC |
NTC |
NTC |
PTC |
| Controller |
Microprocessor |
Microprocessor |
Microprocessor |
Microprocessor |
Microprocessor |
Microprocessor |
Microprocessor |
| Cooling Stystem |
Refrigerant |
R290 (CFC Free) |
R290 (CFC Free) |
R290 (CFC Free) |
R290 (CFC Free) |
R290 (CFC Free) |
R290 (CFC Free) |
R290 (CFC Free) |
| Defrost |
Manual |
Manual |
Manual |
Manual |
Manual |
Manual |
Manual |
| Compressor (Qty) |
CUBIGEL/1 |
CUBIGEL/1 |
CUBIGEL/1 |
CUBIGEL/2 |
CUBIGEL/1
HUAYI/1 |
CUBIGEL/1 |
SECOP/2 |
| Display |
Door ajar |
Door ajar |
Door ajar |
Door ajar |
Door ajar |
Door ajar |
Door ajar |
| Audible & Visible Alarm |
Standard |
High/Low temperature, Sensor error |
| High Ambient Temperature |
/ |
/ |
/ |
Standard |
Standard |
Standard |
Standard |
| Low Battery |
/ |
/ |
/ |
/ |
/ |
/ |
Standard |
| Power Failure Backup System(alarm) |
8h |
/ |
8h |
8h |
8h |
8h |
72h |
| Material |
Internal |
Electro-galvanized steel with antimicrobial powder coating |
Stainless steel
grade 304 |
| External |
Electro-galvanized steel with antimicrobial powder coating |
| Accessories |
USB Port |
/ |
/ |
/ |
Standard |
Standard |
Standard |
Standard |
| Casters |
Standard |
Standard |
Standard |
Standard |
Standard |
Standard |
Standard |
| Remote Alarm Port |
Standard |
/ |
Standard |
Optional |
Optional |
Standard |
Standard |
| Test Hole (Qty / Diameter (mm) |
2/20 |
2/20 |
2/20 |
2/20 |
2/20 |
2/20 |
2/20 |
| Shelves / Drawers (Qty) |
Shelves/3 |
Drawers/7 |
Shelves/4 |
Shelves/4
Drawers/12 |
Shelves/2
Drawers/6 |
Shelves/4
Drawers/18 |
Shelves/3 |
| Sound Emission (dB) |
48 |
50 |
48 |
49 |
50 |
55 |
50 |
| Electricity |
Voltage/Frequency |
AC110/220V±10%, 50/60Hz |
| Consumption (W) |
300 |
280 |
300 |
310 |
430 |
340 |
1000 |
| N.W./G.W. (Kg) |
98.5/118 |
79/104.5 |
110.3/132 |
138/178 |
137/166 |
151/184 |
372/416 |
| Shipping Size (WxDxH) (mm) |
760x760x1750 |
725x665x1850 |
750x760x2030 |
780x920x1990 |
775x920x1990 |
930x970x2000 |
1360x1135x2170 |
-40°C Upright Freezer Features:
- Clear LED screen and control panel support easy display and operation.
- Lockable universal caster wheels.
- Inner doors or drawer design makes separated storage possible.
- Eco friendly CFC-free refrigerant also save energy.
Reliability
- Audible buzzer and visible flashing temperature alarm system for High/low temperature, power failure, sensor error, door ajar, thermostat failure alarm.
- Safety password protected control panel prevents unauthorized system modification.
- Door lock for storage safety.
Ergonomic Design
- Upright door with limit door hinge prevents collision when door opens.
- Controller password protected to avoid unauthorized system modification.
- Lockable universal caster wheels for easy moving.
