HomeHorizontal Laminar Flow Cabinet

Horizontal Laminar Flow Cabinet
Model: LCB-H1100; LCB-H1300; LCB-H1600; LCB-H1900

Work Surface Height : 750mm
Airflow Velocity : Adjustable, 0.2~0.5 m/s
HEPA Filter Efficiency : 1 pcs, Efficiency: > 99.995% at particle size of 0.3μm
Pre-Filter : 1pcs, Polyester fiber,washable
Sound Emission : ≤65dB(A)

The horizontal laminar flow cabinet is suitable for use in biological laboratories, pharmaceutical manufacturing and other laboratory environments where sterile conditions are required.
You can later choose whether you want a quote, or if you place a firm order.

Product Description

Horizontal laminar flow cabinet provides a sterile work zone through a purified air that travels in a horizontal, unidirectional stream and leaves main work chamber across the entire open front of the cabinet. 1pcs prefilter laminar flow cabinet is a popular product for labs. Preferred by large laboratories, pharmaceutical manufacturing and other industries, now the best budget laminar flow cabinet for sale at affordable price.

Laminar Flow Cabinet Features:

  1. Ergonomic control panel location, centered and angled down for an easy reach & viewing.
  2. Brushed stainless steel work surface is for easy cleaning.
  3. The non-direct light source design can effectively relieve the operator’s visual fatigue under the condition of ensuring the illumination.
  4. Intuitive and easy-to-use microprocessor controller with LCD display, graphical and digital display of the operating status of each function, such as filter life, UV life etc.

Reliability:

  1. Front sliding sash interlock with fan and UV lamp.
  2. UV sterilization with UV lamp timing function.
  3. Front sash and side windows are made of UV-resistant tempered glass.
  4. The host and sockets have independent capacitors to prevent current overload.
  5. Memory function in case of power-failure.

Convenience:

  1. HEPA filter and UV life indicators facilitate a timely replacement plan.
  2. Two side glass windows installed for easy experiment observation.
  3. Easy-to-change pre-filter installed could extend the HEPA filter’s lifetime.
  4. Equipped with temperature sensor to show the real temperature during operation.
  5. Waterproof socket provide convenience for small instruments to be used in the operating area.

Laminar Flow Cabinet Specifications:

Model LCB-H1100 LCB-H1300 LCB-H1600 LCB-H1900
External Size (WxDxH)(mm) 1050x805x1950 1320x805x1950 1625x805x1950 1930x805x1950
Internal Size (WxDxH)(mm) 950x490x574 1220x490x574 1525x490x574 1830x490x574
Work Surface Height 750mm
Control System Display Microprocessor controller with LCD display, display the operating status of each function
Interlock Front sliding sash interlock with fan and UV lamp
Life Indicator HEPA filter and UV life indicators facilitate a timely replacement plan
Airflow System Airflow Velocity 0.2~0.5 m/s, speed adjustable
Air filtration System Pre-Filter 1pcs, Polyester fiber,washable
HEPA Filter 1 pcs, Efficiency: > 99.995% at particle size of 0.3μm
Cleanliness Grade ISO Class 5 (formerly Class 100)
Cabinet Construction Main Body Electro-Galvanized steel with antimicrobial powder coating
Work Surface 304 Stainless steel
Front Window Manual sliding sash: 5 mm UV resistant tempered glass with counter-balance system and ergonomic handle
Side window 5 mm UV resistant tempered glass
Electrical System UV Lamp 20W×1 30W×1 30W×1 18W×2
With timing function from 0 to 999 minutes, Interlock with front sliding sash.
Emission of 253.7 nanometers for best sterilization effect.
LED Lamp 6.5W×1 9.6W×1 9.6W×1 6.5W×2
Consumption 160W 170W 300W 310W
Not include socket loading power consumption
Power Supply AC220V±10%, 50/60HZ; 110V±10%, 60Hz
Illumination ≥900Lux
Sound Emission ≤65dB(A)
Standard Accessory 1. Base Stand; 2. LED Lamp; 3. UV Lamp; 4. Waterproof Socket×2
Optional Accessory 1.Gas Tap; 2. IV Bar with Hooks
Gross Weight (kg) 220 260 300 340
Shipping Size (W×D×H)(mm) 1190x1010x1425 1460x1010x1425 1765x1010x1425 2070x1010x1425
Shipping Volume (m³) 1.7 2.3 2.55 3
