Low Temperature Freezer/Pharmacy Refrigerator
Low Temperature Freezer/Pharmacy RefrigeratorLow Temperature Freezer/Pharmacy RefrigeratorLow Temperature Freezer/Pharmacy RefrigeratorLow Temperature Freezer/Pharmacy RefrigeratorLow Temperature Freezer/Pharmacy Refrigerator
Model : FZ-25V90; FZ-25V120; FZ-25V170; FZ-25V230; FZ-25V300; FZ-25V370; FZ-25V570; FZ-25V300D; FZ-25V370D; FZ-25V460D;

Temperature Range : -10 to -25 °C
Sensor : NTC
Temperature Controller : Electronic Thermostat
Cooling Mode : Forced Air Cooling
You can later choose whether you want a quote, or if you place a firm order.

Product Description

Low temperature freezer, also known as medical refrigerator or pharmaceutical refrigerator, are used for the low-temperature preservation of biological products such as bacteria, viruses, plasma, vaccines, erythrocytes, and leukocytes. These pharmacy refrigerators are suitable for use in pharmaceutical factories, pharmacies, disease control centers, community health service centers, as well as laboratories within various universities and research institutions.

Low Temperature Freezer Feature:



  1. High-efficiency refrigeration system with internationally renowned brand compressor, using hydrocarbon refrigerant for strong and efficient cooling.
  2. Air-cooled design inside the cabinet,  optimized evaporator pipeline design, achieving excellent uniformity, fast cooling and less frost.
  3. Microcomputer control, internal temperature adjustable from -10°C to -25°c, setting accuracy 1°c.
  4. Double-layer tempered glass door with electric heating function, ensuring no condensation in highhumidity environment and clear view of samples.
  5. Internal lighting design, multi-layer adjustable shelf design, allowing reasonable gap adjustment according to stored items to makefull use of space.
  6. Precise dimension design, compact size, can be flexibly used on or under the bench, adjustable fixed feet design for stable placement.
  7. Wide voltage design to ensure stable operation of the equipment.

Low Temperature Freezer Specification:

Model FZ-25V90 FZ-25V120 FZ-25V170 FZ-25V230 FZ-25V300 FZ-25V370 FZ-25V570 FZ-25V300D FZ-25V370D FZ-25V460D
Capacity (L) 90 116 168 228 300 368 568 300 365 458
Temperature Range -10 to -25 °C
Sensor NTC
Temperature Controller Electronic Thermostat
Cooling Mode Forced Air Cooling
Cooling Liquid Green cooling liquids (R290)
Defrost Mode Auto defrost
Compressor Qty 1
Shelf/Drawer Qty 3 3 6 4 5 6 6 3 6 9
Refrigerant Weight (g) 60 60 120 95 115 125 155 125 130 150
Comsuption (W) 260 260 520 550 580 550 695 550 650 695
Daily Power Consumption (W) 3.79 4.26 6.9 8.52 7.86 8.9 10.52 9.87 13.78 13.32
Noise (dB) 43 45 44 43 44 43 45 44 43 45
Power Supply 220/110 V, 50/60 Hz
Display LED
Inside Material Spray coated
Outside Material Spray coated cold-rolled steel plate
Alarm High/low temperature, Power failure, Sensor error, Thermostat failure (Optional),  High ambient temperature (Optional), Door ajar
Exterior Size (W×D×H)(mm) 595×584×950 720×584×970 406×579×1931 635×624×1449 595×668×1859 660×714×1985 895×714×2166 1250×605×1110 1500×605×1110 1860×605×1110
Package Size (W×D×H)(mm) 675×630×1075 790×630×1080 535×682×2010 700×655×1535 681×700×2007 760×730×2075 755×985×2320 1325×645×1335 1580×642×1300 1935×660×1270
Accessory 4 pcs Castor;
1 pc Test hole, 25 mm diameter;
N.W./G.W.(kg) 63/73 72/76 86/90 87/95 100/114 126/134 156/178 100/126 105/136 154/167
