Cryobiobank Liquid Nitrogen Tank

Home » Avik Product Catalogue » Cryobiobank Liquid Nitrogen Tank

Model : LNC-350-326C; LNC-450-326C; LNC-550-445C; LNC-750-445C; LNC-850-465C

LN₂ Capacity Under Platform Vapor Storage(L) : 55 / 55 / 80 / 80 / 135
LN₂ Capacity (L) : 350 / 460 / 587 / 783 / 890
Neck Opening (mm) : 326 / 326 / 445 / 445 / 465
Usable Internal Height (mm) : 600 / 828 / 600 / 828 / 773

Cryobiobank Liquid Nitrogen Tank is suitable for biological samples that require long-term preservation, it provides a reliable storage solution for experiments in medical research, biomedical engineering and other fields.

You can later choose whether you want a quote, or if you place a firm order.

Product Description

Cryogenic technology is a critical area in laboratories, particularly for the storage and preservation of cells, biological samples, tissues, and other temperature-sensitive materials. Cryogenic systems maintain extremely low temperatures (typically below -150°C) to preserve the integrity of samples for long-term storage or transport.

Liquid Nitrogen Tank Specifications:

Model	LNC-350-326C	LNC-450-326C	LNC-550-445C	LNC-750-445C	LNC-850-465C
LN₂ Capacity Under Platform Vapor Storage (L)	55	55	80	80	135
LN₂ Capacity (L)	350	460	587	783	890
Neck Opening (mm)	326	326	445	445	465
Usable Internal Height (mm)	600	828	600	828	773
Outer Diameter (mm)	875	875	1104	1104	1190
Overall Height(mm) Containing Instrument Height	1326	1558	1321	1591	1559
Weight Empty (kg)	219	277	328	372	441
Operation Height (mm)	1263	1212	1266	1216	980
Weight Liquid Full (kg)	502	649	802	1005	1160
Door Width Requirement (≥mm)	895	895	1124	1124	1210
Maximum Storage Capacity of 2ml Internal Rotary Freeze Storage Tube
1.2,1.8 & 2 ml Vials (Internally Threaded) (ea)	13000	18200	27000	37800	42900
Number of Racks With 25 (5×5) Cell Boxes (ea)	4	4	12	12	4
Number of Racks With 100 (10×10) Cell Boxes (ea)	12	12	24	24	32
Number of 25 (5×5) Cell Boxes (ea)	40	56	120	168	52
Number of 100 (10×10) Cell Boxes (ea)	120	168	240	336	416
Number of Stages Per Rack (ea)	10	14	10	14	13
Maximum Straw Capacity
High Security Straw Capacity (0.5 mL) (ea)	111312	131220	203040	253800	304920
High Security Straw Capacity (0.25 mL) (ea)	254592	301120	468544	585680	699360
Number of Canisters (76 mm) (ea)	52	52	112	112	120
Number of Canisters (63 mm) (ea)	8	8	0	0	16
Number of Canisters (38 mm) (ea)	28	12	24	24	40
Number of Levels Per Canister (ea)	4	5	4	5	5
Level Height (mm)	135	135	135	135	135
Gross Weight (kg)	274	340	396	448	524.1
Shipping Size (WxDxH) (mm)	1020x1020x1520	1020x1080x1740	1250x1250x1510	1380x1250x1750	1440x1330x1750

Maximum Blood Bag Capacity
Blood Bag Type	25 mL (791 OS/U)	50 mL (4R9951)	200 mL (DF-200)	250 mL (4R9953)	500 mL (4R9955)	700 mL (DF-700)
Total Bags	1296	792	168	300	192	96
Bags/ Frame	6	6	3	3	3	3
No. Frames	216	132	56	100	64	32
Total Bags	1728	1056	280	500	320	128
Bags/ Frame	8	8	5	5	5	4
No. Frames	216	132	56	100	64	32
Total Bags	2376	1416	336	552	408	204
Bags/ Frame	6	6	3	3	3	3
No. Frame	396	236	112	184	136	68
Total Bags	3168	1888	560	920	680	272
Bags/ Frame	8	8	5	5	5	4
No. Frames	396	236	112	184	136	68
Total Bags	3360	2072	544	944	640	320
Bags/ Frame	7	7	4	4	4	4
No. Frames	480	296	136	236	160	80

Liquid nitrogen tank used in hospitals and research institutions to build biological sample banks, common tissues and organ banks, such as blood bank, corneal bank, bone marrow bank; Cell line library of normal cells, genetic mutation cells, tumor cells and hybridoma cell lines; Various stem cell banks such as cord blood stem cell banks and embryonic stem cell banks, as well as genome banks of various races and diseases.

Liquid Nitrogen Tank Features:

Compatible with vapor and liquid storage modes.
Various capacity optional to meet your storage requirements.
More specimen capacity in a limited space to reduce the storage costs.
One button to demist, easy to search, pick and place specimen.
User-friendly design, comfortable operation.
Equipped with folding steps and workbench.

Reliability

Advanced temperature, level monitoring and alarm system, microprocessor-based control system and the vertical double platinum resistance temperature probe can display real time temperature.
The user can set their own alarm temperature value, with alarm mute option.
Automatic filling liquid nitrogen system, safe and efficient.
Lockable lid, fully guarantee the safety of the specimen.
Excellent temperature uniformity and stability, vacuum insulated stainless steel structure, high vacuum coverage to ensure excellent insulation properties.
Excellent temperature stability after opening lid, innovative lid and excellent small neck openings design can greatly reduce the liquid nitrogen evaporation rate.
Controlling system can permanently store operating data.
