HomeDigital Ultrasonic Cleaner

Home » Avik Product Catalogue » Digital Ultrasonic Cleaner

Model: UC-D Series

Ultrasonic Freq(KHz) : 40

Temperature Setting(℃)-Max : 80℃

Time Setting(min) : 180s/360s or 1-30 mins
The 40 kHz ultrasonic cleaner a wide range of materials and the tank is made of stainless steel for corrosion resistance and easy cleaning.

You can later choose whether you want a quote, or if you place a firm order.

Product Description

Digital ultrasonic cleaner also known as ultrasonic bath uses advanced ultrasonic technology to remove dirt, grease and grime using high frequency sound waves. Our ultrasonic bath for sale at an affordable price. Ideal for cleaning jewellery, medical equipment, automotive parts and laboratory equipment. The digital control panel provides precise time and temperature settings to ensure optimal performance for every task.

Digital Ultrasonic Cleaner Specifications:

Model	UC-D	UC-D1	UC-D2	UC-D3	UC-D5	UC-D4	UC-D6	UC-D7	UC-D10	UC-D15	UC-D20	UC-D25	UC-D30	UC-D45
Tank Capacity (L)	0.6	1.3	2	3.2	4.8	4.5	6.5	7	10	15	20	22	30	45
Transducer Qty (Pcs)	1	1	1	2	2	3	3	4	4	6	6	8	10	12
Ultrasonic Freq (KHz)	40
Temperature Setting (℃)-Max	/	80
Drain Valve	No							Yes
Time Setting(min)	180s/360s	1-30 mins
Cleaning Basket	Yes
Carrying Handle	No			Yes
Ultrasonic Power(W)-Max	50	70	70	120	120	180	180	240	240	360	360	480	600	720
Heating Power(W)-Max	/	100	100	100	100	200	200	500	500	500	500	500	500	1000
Chamber Size (W×D×H)(mm)	150x85x65	150x135x65	150x135x100	240x135x100	240x135x150	300x150x100	300x150x150	300x240x100	300x240x150	330x300x150	330x300x200	500x300x150	500x300x200	500x300x300
Size (W×D×H)(mm)	175x110x155	180x165x205	180x165x240	265x165x235	265x165x285	330x180x260	330x180x310	330x270x260	330x270x310	360x330x330	360x330x380	530x330x340	530x330x390	530x330x490
Shipping Size (W×D×H)(mm)	560x510x460	520x510x310	520x510x335	360x260x320	735x520x400	570x440x370	570x440x410	470×350×350	470×350×350	500×410×410	500×400×455	690×410×420	690×410×470	690×410×590
Packing Quantity	12pcs	4pcs	4pcs	1pc	4pcs	2pcs	2pcs	1pc	1pc		1pc	1pc	1pc	1pc
N.W./G.W. (kg)	1.6/22	2.6/13	2.8/14	3/4.5	4.1/21	5.2/14	5.8/25	7/9	7.8/10	10/13	10.5/13	13/16	15/18	19/23
