Home » Avik Product Catalogue » Dry Shipper Liquid Nitrogen Tank
Model : LNC-1-50D; LNC-3-80D; LNC-4-125D; LNC-9-216D
Effective Capacity (L) : 1.3 / 2.9 / 3.4 / 9
Neck Opening (mm) : 50 / 80 / 125 / 216
Static Evaporation Rate (L/day) : 0.16 / 0.2 / 0.43 / 0.89
Static Holding Time (day) : 20 / 37 / 23 / 29
Ensure optimal safety with the Dry Shipper Liquid Nitrogen Tank – ideal for transporting infectious materials or biological samples at low temperatures.
This dry shipper liquid nitrogen tank is a container for cryogenic transport. It is mainly used for transporting items that need to be kept at low temperatures, such as biological samples, cells, vaccines and so on. Nitrogen liquid container adopts vacuum insulation technology and contains a certain amount of liquid nitrogen inside, which can maintain the low temperature environment for several months.
Dry Shipper Liquid Nitrogen Tank Specifications:
| Model |
LNC-1-50D |
LNC-3-80D |
LNC-4-125D |
LNC-9-216D |
| Performance |
| Effective Capacity (L) |
1.3 |
2.9 |
3.4 |
9 |
| Weight Empty (kg) |
3.2 |
4.9 |
6.7 |
15 |
| Neck Opening (mm) |
50 |
80 |
125 |
216 |
| Outer Diameter (mm) |
223 |
300 |
300 |
394 |
| Overall Height (mm) |
435 |
487 |
554 |
716 |
| Static Evaporation Rate (L/day) |
0.16 |
0.2 |
0.43 |
0.89 |
| Static Holding Time (day) |
20 |
37 |
23 |
29 |
| Effective Shelf Life |
8 |
14 |
8 |
10 |
| Maximum Storage Capacity |
| Canister |
Canister Diameter (mm) |
38 |
63 |
97 |
/ |
| Canister Height (mm) |
120 |
120 |
120 |
/ |
| Number of Canisters (ea) |
1 |
1 |
1 |
/ |
Straws Capacity
(120 mm Canister) |
0.5 mL (ea) |
132 |
374 |
854 |
/ |
| 0.25 mL (ea) |
298 |
837 |
1940 |
/ |
Racks
&Vials
Boxes |
Number of Racks (ea) |
/ |
/ |
1 |
1 |
| Vial Boxes Size (mm) |
/ |
/ |
76×76 |
134×134 |
| Boxes Per Rack (ea) |
/ |
/ |
4 |
5 |
1.2;1.8&2 mL Vials
(Internally Threaded) |
/ |
/ |
100 |
500 |
25 mL
Blood Bag |
Number of Racks (ea) |
/ |
/ |
1 |
1 |
| Stages Per Rack (ea) |
/ |
/ |
1 |
2 |
| Boxes Per Stage (ea) |
/ |
/ |
3 |
15 |
| Blood Bag Capacity (ea) |
/ |
/ |
3 |
30 |
50 mL
Blood Bag |
Number of Racks (ea) |
/ |
/ |
1 |
1 |
| Stage Per Rack (ea) |
/ |
/ |
1 |
1 |
| Boxes Per Stage (ea) |
/ |
/ |
3 |
15 |
| Blood Bag Capacity (ea) |
/ |
/ |
3 |
15 |
| Gross Weight (kg) |
4.48 |
6.74 |
8.56 |
19.54 |
| Shipping Size(WxDxH)(mm) |
270x270x510 |
340x340x555 |
340x340x615 |
425x425x800 |
| Optional Accessories |
| Lockable Lid |
Standard |
Standard |
Standard |
Standard |
| PU Bag (Protective Jacket) |
Standard |
Standard |
/ |
/ |
| Smart Cap |
/ |
/ |
/ |
/ |
Dry nitrogen tank series is suitable for cryogenic environment (vapor storage at temperatures below -190 °C) transportation for samples. It could avoid the risk of the liquid nitrogen releasing during transportation, especially designed for short-term air transport. Dry nitrogen tank mainly used for laboratory users and short-term delivery of small number samples.
Nitrogen liquid container Features
- Vapor cryogenic storage
- Fast liquid nitrogen filling
- High strength aluminum construction
- Straws or vials storage is optional
Reliability
- Three years vacuum warranty
- Lockable lid
- No liquid nitrogen overflow
