Model : LNC-2-30P; LNC-2-35P; LNC-3-50P; LNC-6-50P; LNC-10-50P

LN₂ Capacity (L) : 2 / 2 / 3 / 6 / 10
Neck Opening (mm) : 30 / 35 / 50 / 50 / 50
Static Evaporation Rate (L/day) : 0.07 / 0.08 / 0.12 / 0.12 / 0.12
Static Holding Time (day) : 28 / 24 / 26 / 52 / 86
Canister Diameter (mm) : 19 / 25 / 38 / 38 / 38

Cost-effective storage and transport of liquid nitrogen.

You can later choose whether you want a quote, or if you place a firm order.

Product Description

Liquid Nitrogen Container Specifications:

Model		LNC-2-30P	LNC-2-35P	LNC-3-50P	LNC-6-50P	LNC-10-50P
Performance
LN₂ Capacity (L)		2	2	3	6	10
Weight Empty (kg)		2.8	2.6	3.1	4.8	6.1
Neck Opening (mm)		30	35	50	50	50
Outer Diameter (mm)		223	204	223	300	300
Overall Height (mm)		399	428	435	482	552
Static Evaporation Rate (L/day)		0.07	0.08	0.12	0.12	0.12
Static Holding Time (day)		28	24	26	52	86
Maximum Storage Capacity
Canister Diameter (mm)		19	25	38	38	38
Canister Height (mm)		120	120	120	120	120
Number Of Canisters (ea)		3	3	6	6	6
Straws Capacity (120 mm Canister)	0.5ml (ea)	90	165	792	792	792
Straws Capacity (120 mm Canister)	0.25ml (ea)	204	330	1788	1788	1788
Straws Capacity (276 mm Canister)	0.5ml (ea)	/	/	/	/	/
Straws Capacity (276 mm Canister)	0.25ml (ea)	/	/	/	/	/
Gross Weight (kg)		4.1	3.9	4.8	7	7.9
Shipping Size(WxDxH) (mm)		260x260x465	220x220x495	270x270x510	340x340x555	340x340x615
Optional Accessories
Lockable Lid		Standard	Standard	Standard	Standard	Standard
PU Bag (Protective jacket)		Standard	/	Standard	Standard	Standard
Smart Cap		/	/	Standard	Standard	Standard

Portable storage series is made of high strength light aluminum alloy and contains multi-layer super-strong heat insulation layer. It realizes the safety, lightness and efficiency of the product.An economical and practical small liquid nitrogen tank specially designed for biological samples that need to be stored regularly.
